Key Specifications

Dimensions & Handling

• Minimum Fork Height: 85 mm
• Maximum Fork Lift: 800 mm
• Overall Length: 1652 mm
• Fork Length: 1245 mm
• Fork Width Options: 550 / 685 mm
• Turning Radius: 1480 mm

Wheel Configuration

• Steering Wheel: Ø180 × 50 mm
• Load/Fork Wheels: Ø74 × 50 mm

Operating Space

• Aisle Requirement for 1000 × 1200 mm Pallet (Crosswise): 1852 mm
• Aisle Requirement for 800 × 1200 mm Pallet (Lengthwise): 1852 mm

Motor & Battery

• Lift Motor Power: 0.7 kW (S3 15%)
• Battery: 12 V / 100 Ah (K10)
• Battery Weight: 31 kg
• Total Service Weight with Battery: 181 kg

Suitable Applications

This hand pallet truck can be used for:

• Warehouse pallet transportation
• Factory material handling
• Distribution and logistics operations
• Loading and unloading areas
• General industrial material movement
